Description

Fits

Year	Make	Model	Engine
2020-2025	Chevrolet/GMC	2500/3500	6.6L Duramax w/10 Speed Allison 10L 1000 Transmission

Banks adds their Ram-Air cooling to the heavy-duty Allison 10L1000 transmission for 2020-2025, using technology from their patented differential covers. The Banks Ram-Air Transmission Pan keeps fluid oil fresh by expelling more heat than stock and other brands. It also provides three extra quarts of space, a break-away Ram-Air scoop, and Banks FlowThru Fins for maximum cooling. With cooler fluid, your transmission will last longer.

Part Number: 35148-B

Features

Engineered for the highest heat rejection, improved oil flow, and full oil drainage
Adds 3 additional quarts of fluid capacity
Internal fins transfer heat through the cover into the external fins
123% more heat absorption surface area than stock
134% more cooling surface area than stock
Breakaway Ram-Air Scoop Design Prevents Pan Damage
Internal geometry allows full fluid drainage

Notes

Will work with AEV skid plates
Transmission Pan Gasket: 2020-2024 GM Part No. 24297922
Transmission Fluid Filter: 2020-2024 GM Part No. TF938 or 24298004

Additional Info

Fluid Dynamics

Internal cooling fins run inline with the drain port with streamlined passageways
Downward-facing port eases oil change process
Low fluid aeration means longer fluid life

Technical Specs

1/8 NPT port for aux temp sensor
External heat radiation fin count: 22
Internal heat absorption fin count: 20
External heat radiation surface area: 1005 in²
Internal heat absorption surface area: 835 in²
Fasteners: 16 x stainless steel M6 flange hex bolts
Material: A380 aluminum diecast with CNC machined surfaces

Oil service

High temp resistant Ferrite Magnetic Drain Plug
Fully drains oil pickup tube for quicker oil changes
Banks recommends Amsoil ATF
Adds 3.0 quarts additional capacity (Check OEM Owners Manual)
