Base Kit


2001-2010 Duramax 6.5" 2.5 Series Front Coilover (884-06-188)-Front Shock-FOX-884-06-188-Dirty Diesel Customs

Fox 2.5 Series Remote Reservoir Coilovers

When you want the best in performance and capability, go with FOX. These race-proven FOX 2.5 factory series remote reservoir coilovers up the ante allowing for next-level damper capability and control all neatly packaged. Designed for bolt-on installation, the engineers at BDS and FOX teamed up to offer this race-winning technology into a bolt-on, pre-tuned Coilover designed to perform and provide correct ride height right out of the box. From valving to spring rate, preload, and hose length; designed to take all the guesswork out of setting your vehicle up and are designed to be used with BDS lift systems. These coilovers use a large 2.5" body, 3" coil springs, 7/8" hardened carbon steel shaft, high flow piston, JM92 advanced racing shock oil, CNC machined 6061 T6 ends, and external remote reservoir to improve damper capability across any terrain.

Show more

Coilover Mounting Kit


Coilover Mounting Kit

This Box Kit includes the following products:

  • Driver & Passenger Side Upper & Lower Coilover Mount
  • 2 Reservoir Brackets
  • Bolt Pack - Coilover Mounting
  • Bag Kit
  • 6 11.5" Zip Ties
  • 2 Small 'L' brackets
  • 2 7/8" x 0.406 mounting hole clamps
  • 2 Offset Brakeline Brackets
  • 8 Nut Tabs
  • Bag Kit
  • 2 Aluminum Control Arm Spacer
  • Bolt Pack - Main Hardware Kit

Show more

Coilover Box Kit (1 of 2)


Coilover System Box Kit

This Box Kit includes the following products:

  • 2 10" Sway Bar Links
  • Bolt Pack
  • Bolt Pack - Sway Bar Links
  • Bolt Pack - Skid Plate Mounting
  • Passenger Side HD Differential Drop
  • Differential Skid Plate
  • Front Differential Bracket
  • Bag Kit
  • 3/4" X 0.090 X 2.950 Sleeve
  • HD Weld-in Plate
  • 2 Hourglass Bushings - Wide
  • 4 Stem Bushings
  • 4 Stem Washers
  • 2 3/4" x 9/16" ID x 1.575" Rolled Sleeves
  • Loctite
  • 6 11.5" Zip Ties
  • Bag Kit
  • 2 Offset Sway Bar Brackets
  • 2 Front Diff Poly Bushings

Show more

Coilover Box Kit (2 of 2)


Coilover System Box Kit

This Box Kit includes the following products:

  • Front & Rear Crossmember
  • Passenger Side HD Differential Tube
  • Sticker Tube
  • Bag Kit - HD Driveshaft Boot Extension
  • HD Driveshaft Boot Extension
  • 4x42 O-Ring
  • #322 O-Ring

Show more

Standard Knuckle Kit


HD Standard Knuckle Kit

This Box Kit includes the following products:

  • Driver & Passenger Side Steering Knuckle
  • Bolt Pack - CV Spacer
  • 12 10mm-1.5 x 70mm SHCS
  • 2 CV Spacer
  • 2 Steering Stop

Show more

Skid Plate


2001-2010 Duramax 4.5" Lift Front Skid Plate (BDS121624)-Skid Plates-BDS-BDS121624-Dirty Diesel Customs

Front Skid Plate


Show more

Rear Lift Option


5" Flat Rear Block Kit

This Box Kit includes the following products:

  • 4 9/16" x 2-9/16" x 15" Square U-Bolts
  • 2 5" Flat Block
  • Bag Kit - 5" Block Kit
  • 8 9/16" Fine High Nuts
  • 8 9/16" SAE Washers

Show more

2001-2010 Duramax 5" Lift Rear Leaf Spring (BDS001509)-Leaf Springs-BDS-BDS001509-Dirty Diesel Customs

5" Lift Leaf Spring (2x)

BDS Glide-Ride leaf springs will reduce axle wrap and create a more controlled and stable feel when towing. The actual leaf spring may not be exactly as shown in the photo. Includes OE-style bushings installed.

Show more

Rear Shocks
