2000-2002 Cummins 5" Long Arm Lift Kit (BDS219H)
Your 24 Valve is a legendary truck, and whether or not you're talking about a barn find sub 50k example or you've got a 500,000-mile work truck, it'll benefit from a 5" Long Arm lift! This long arm kit gives you greater control as your truck works through its suspension travel because it reduces caster and control arm angle changes. If you're going to go to all the work of lifting it you want to make sure you use the best parts! This BDS kit comes with every part needed to drive in and drive out of the shop!
Tire & Wheel Combinations:
- 35" x 12.50" w/ 16 x 8 and 4"
Notes:
- May require exhaust modification
- These vehicles were produced with and without top-mounted overload springs. You will need to identify which your vehicle has before ordering the rear block & add-a-leaf kit.
- Pictured with rear spring option. Rear spring option is NOT included. Please reach out if you would like your kit customized.
Installation:
- Click Here For Installation Instructions
- Difficulty: 3 (where 1 = easiest and 5 = complicated)
Part Number: BDS219H
6" Front Coil Springs
Show more
Long Arm Box Kit
This Box Kit includes the following products:
- Upper & Lower Control Arm
- Driver & Passenger Side Sway Bar Drop Brackets
- 2 Bump Stops
Show more
Long Arm Box Kit
This Box Kit includes the following products:
- Pitman Arm
- Driver & Passenger Side Long Arm Brackets
- Track Bar Bracket
- Driver & Passenger Side UCA Relocation Brackets
- 8 7/8” ID LCA Bushings
- 8 UCA Bushings
- 2 1/4”-28 Grease Zerks
- 6 90° 1/4-28 Grease Zerks
- 5 Flat Brake Line Drop
- 2 Brake Line Drop with Tab
- Brake Line U Drop Bracket
- 5 Track Bar Washer
- Loctite
- 2 3/4” x .120” x 2-3/8” Sleeves
- 4 7/8” x .120” x 2-1/2” Sleeves
- 4 3/4” x .095” x 2-1/4” Sleeves
- 3 Bolt Packs
Show more
The system is available with either the standard block & add-a-leaf kit or replacement BDS Glide-Ride Springs. If choosing the rear block & add-a-leaf option, be sure to check if your vehicle is equipped with a top-mounted overload spring or not. The top-mounted overload spring requires a different rear block & add-a-leaf kit. Please make the appropriate selection.
4.5" Rear Block w/o Top Overload w/ Add-A-Leaf
Show more
4.5" Rear Block Kit w/ Overload w/ Add-A-Leaf
Show more
4.5" Lift Leaf Spring (2x)
Show more
Required if you have selected full Leaf Spring replacements.
No Thanks
Rear Block Kit
Show more
NX2 Series Shocks (2x)
The BDS NX2 series gas shocks offer impressive performance on and off-road. Standard in most BDS lift kits, these nitrogen-charged, twin-tube shocks offer 10-stage velocity-sensitive valving for lightning-fast damper performance and control.
Show more
NX2 Series Shocks (2x)
Show more
Fox 2.0 Series Shocks (2x)
Show more
NX2 Series Single Steering Stabilizer
Show more
Fox 2.0 Dual Steering Stabilizer (2x)
A dual steering stabilizer greatly increases control and reduces unwanted steering wheel shimmy. Choose this option to add dual Fox 2.0 series steering stabilizers.
Note:
- Some 2500 trucks came with a heavy-duty front axle with a larger diameter axle. Measure 2500s first before ordering.
- 1994-2002 Ram 1 Ton trucks MUST HAVE 3" Front Axle. MEASURE BEFORE ORDERING.
Show more
Required if you have selected Dual Steering Stabilizers.
Dual Steering Stabilizer Bracket Kit
Show more
No Thanks
Carrier Bearing Drop Kit
Show more
No Thanks
Rear Sway Bar Links
Show more
No Thanks
Transfer Case Components Indexing Ring
Show more
