1994-1999 Cummins 4WD 2" Coil Spacer Lift Kit (BDS204H_94-99_3/4_Ton)

Keep it riding tall and true with this BDS Suspension 2" Coil Spacer Lift Kit. This 2" leveling kit comes with two cast aluminum upper coil buckets. These buckets bolt solid to your upper coil pocket giving you 2" of lift while maintaining your factory ride quality. Perfectly suited to level the stance of your Dodge truck. Front and rear NX² series shock absorbers are included with your lift kit to make sure you have the proper geometry for your new ride height!

Tire & Wheel Combinations:

  • 33" x 12.50" w/ and 4"

Notes:

  • The 8800 GVW version of the 3/4 ton Dodge actually requires a different front shock. You will need to check the GVW of your vehicle to ensure that you get the correct front shocks.

Installation:

Part Number: BDS204H_94-99_3/4_Ton

Base Kit


1994-2012 Dodge 2" Coil Spacer (BDS012201)-Coil Spacer-BDS-BDS012201-Dirty Diesel Customs

2" Front Coil Spacer

This Box Kit includes the following products:

  • Steering Knuckle - Standard
  • 2 Spacers
  • 1 Hardware Pack
  • 6 7/16 x 1 3/4” Bolt
  • 6 7/16” Lock washers

Show more

Front Shocks

The GVW of the vehicle actually changes the shocks that are needed for this application. The NX² series shocks and the Fox 2.0 performance series gas shocks are both available for vehicles below 8800 GVW or above 8800 GVW.

1994-2017 Powerstroke/Cummins 0-2" Lift NX2 Front Shock Absorber (BDS85710)-Shocks-BDS-BDS85710-Dirty Diesel Customs

NX2 Series Shocks - (< 8800) (2x)

Note: Choose this option for NX² series shocks for vehicles with a GVW less than 8800 lbs.

The BDS NX2 series gas shocks offer impressive performance on and off-road. Standard in most BDS lift kits, these nitrogen-charged, twin-tube shocks offer 10-stage velocity-sensitive valving for lightning-fast damper performance and control.

Show more

1994-2021 Cummins/Powerstroke 0-4.5" Lift NX2 Shock Absorber (BDS85700)-Shocks-BDS-BDS85700-Dirty Diesel Customs

NX2 Series Shocks - (> 8800) (2x)

Note: Choose this option for NX² series shocks for vehicles with a GVW greater than 8800 lbs.

The BDS NX2 series gas shocks offer impressive performance on and off-road. Standard in most BDS lift kits, these nitrogen-charged, twin-tube shocks offer 10-stage velocity-sensitive valving for lightning-fast damper performance and control.

Show more
