2022-2024 Cummins AMDP EZ-Lynk Support Pack

Now released: unlock and tune through the OBD-II port. No ECM unlock send-in service and no ECM swap needed. It flashes over OBD just like the 2019-2021 trucks.

Note: This product provides tune files and AMDP support only. An EZ-Lynk Auto Agent 3.0 and an SGW bypass cable are required and are not included.

AMDP calibrations for the 2022-2024 Ram 6.7L Cummins, developed in-house and delivered over the air through the EZ-Lynk Auto Agent. The factory file is written with margin for the entire fleet, with conservative fueling, restrained boost targets and a pedal map that makes the truck feel lazy. AMDP's calibrations are built to fix that, with reliable power gains, sharper throttle response and smoother drivability whether you are towing, daily driving or chasing a number.

Power Levels - 0 to 150 HP over stock:

• Level 1 - approx. 30 HP
• Level 2 - approx. 60 HP
• Level 3 - approx. 90 HP
• Level 4 - approx. 120 HP
• Level 5 - approx. 150 HP

• Custom calibrations developed in-house by AMDP and flashed over the air through the EZ-Lynk Auto Agent, with no ECM swap or bench flash required
• Five power levels from roughly 30 to 150 HP over stock
• Shift On The Fly between power levels through the CCV switch (switch sold separately)
• Optional transmission tuning for 68RFE or Aisin equipped trucks: enhanced shift points, firmer shifts and reduced torque management for smoother power delivery and improved durability
• Supports custom modifications including turbos, built transmissions and fuel system upgrades
• Choice of 4-Week (Limited) or Lifetime (Full) support package
• Mobile access to AMDP's custom tuning and tune updates through the Auto Agent app

• This product provides tune files and support only. An EZ-Lynk Auto Agent 3.0 is required and is not included.
• An SGW bypass cable is required - the standard cable used on all 2018+ Ram trucks.

• The CCV switch used for Shift On The Fly is sold separately.
• A battery charger or maintainer (12+ amps recommended) is required during flashing to prevent a voltage drop from interrupting the process.
• Your VIN is required and is collected at checkout.
• AMDP does not support lope tunes or smoke tunes.

• Single tune or Shift On The Fly? Both are available. Shift On The Fly switches power levels through the CCV switch.
• Standard and HO trucks? Yes, this covers all standard-output and high-output 6.7L Cummins trucks.
• Already running the zero-HP no-swap tuning? Yes. This works on trucks tuned with the AMDP EZ-Lynk No ECM Swap tuning and on HP Tuners unlocked ECMs.
• Which bypass cable? The EZ-Lynk 3.0 OBDII patch cable (100EE00C23), the standard cable used on all 2018+ Ram trucks.

Required items:

• AMDP custom tuning support pack (this product - choose Limited or Full support)
• EZ-Lynk Auto Agent 3.0
• SGW bypass cable (the standard one for all 2018+ Ram trucks)

2022-2024 Cummins EZ-Lynk flashing instructions:

1. Purchase and prepare. Order your AMDP custom tuning support pack and make sure you have every required item listed above.
2. Install the security bypass cable. Attach the security bypass portion as directed. This bypasses the factory security gateway module for reliable flashing.
3. Connect the EZ-Lynk Auto Agent. Plug the Auto Agent 3.0 into the OBD-II port.
4. Connect a battery maintainer. Attach a battery charger or maintainer to the truck (12+ amps recommended) to prevent any voltage drop during the process, which could interrupt flashing.
5. Flash your custom tune. Once the data transfer is complete you are ready to flash your desired AMDP custom tune.

Click here to view the general EZ-Lynk Auto Agent setup guide
