2007.5-2024 Cummins Ram-Air Transmission Pan (35170-B)

Name: 2007.5-2024 Cummins Ram-Air Transmission Pan (35170-B)
Brand: Banks Power
SKU: 35170-B
Price: 622.05 CAD
Availability: InStock

(5)

Banks Power Part Number: 35170-B

$622.05 CAD

Purchase to earn 622 Dirty Dollars Learn More

This product ships for free to most Canadian locations! Learn more

Truck Fitment

Description

Note: Not designed for the high-output 6.7L Cummins

Keep your 68RFE transmission running cooler and stronger with the Banks Ram-Air Transmission Pan. Patented Ram-Air scoop and FlowThru fins deliver faster heat transfer, extending fluid life and durability under heavy-duty use. With +3 quarts of capacity and a breakaway scoop, this die-cast pan outperforms stock and competitors alike.

Part Number: 35170-B

Features

Lowers transmission fluid temps
Ram-Air scoop forces airflow
FlowThru® fins for rapid cooling
+3 quarts fluid capacity
Full fluid drainage design
Die-cast, durable construction
Breakaway scoop prevents damage

Notes

Requires the 68RFE 6-speed transmission

Installation

Click Here For Instructions

Questions and Answers

Don't see your question? Ask us anything about this product.

?
does it come with a new gasket
No, the Banks Power Ram-Air Transmission Pan (35170-B) does not come with a new pan gasket.
- If your current gasket is in good shape: You can simply wipe it clean and reuse it during installation.
- If your current gasket is leaking or worn: You will need to source a new one separately.
- Avoid RTV: Banks recommends against using RTV Ultra Grey or similar liquid gasket makers unless your original reusable gasket is physically missing or damaged
Will this fit on a 2015 ram 1500 with a 65rfe

No.
This pan ok with an Aisin tranny

No, this pan will not fit an Aisin transmission. It's designed exclusively for the 68RFE transmission.
Does this pan come with a seal and a drain plug?

It does not come with the seal or filter, it comes with the plugs and a seal install tool however.
Do i need a filter spacer?

No!
Does it come with a gasket or should I use RTV Ultra Grey?

As per Banks Power's technical support, this pan is engineered to work best with the factory (OEM) reusable gasket. You should not use RTV Ultra Grey unless your factory gasket is damaged or missing, as the 68RFE system is designed for a high-quality rubber-over-steel reusable gasket.
