Universal 35W XB35 2.0 Computer (BL15)
Morimoto
Part Number:
BL15
$84.00 CAD
Unit price
/
Unavailable
Purchase to earn 84 Dirty Dollars Learn More
Description
Description
Fits
| HID BULBS | Any with 'AMP' style inputs |
| VEHICLES | All with 9-18V electrical systems |
Note: Igniters NOT included
When two of the best names in ballasts get together to create something new, good things happen. The new XB is essentially a Hylux + Morimoto mash up, and we are proud to bring their new ballast baby to North America!
Designed to last for 2500 hours and we're confident they will. The powerful AS15-G4 IC chip recognizes outside system faults such as a loose high voltage connection, and after one misfire will cut power rather than potentially self-destruct. The software is proprietary to this ballast alone.
Part Number: BL15
Features
Features
- Stainless Steel hardware
- Die-cast aluminum shell houses a 100% potted circuit board; eliminating any chance of moisture damage
- TechFlex braided insulation
- Consumes less than half of the start current the previous did
- Slim 18mm body
- Easily change from AMP to D2S or vice-versa (without the use of unreliable adapters
- XB has relocated igniters far closer to the HID bulb - which reduced radio interference
Additional Info
Additional Info
| OUTPUT WATTAGE | 35W +/- 2% |
| OUTPUT CURRENT | 85V AC |
| IGNITION VOLTAGE | 23KV |
| INPUT VOLTAGE | 9-18V DC |
| INPUT CURRENT | 5A @ Startup |
| OPEN CIRCUIT | Protected (< 1s) |
| SHORT CIRCUIT | Protected (< 1s) |
| CLIMATE RANGE | -40C to +85C |
| RATED LIFESPAN | 2500hours (5-7 years) |
What's Included
| BALLASTS | 1x Morimoto XB35 2.0 Computers |
| WARRANTY | 2 Years |
