2019-2023 Cummins 6" Lift Kit w/ Bilstein Shocks w/ Ring & Crossmember (49-1961)

Fits

A popular ReadyLIFT option to lift your 2500 HD an upgrade from the 49-1960 premium lift kit, this kit includes the new DIS re-positioning components to ensure a smooth ride and great handling, no more vibration, and over-compression.

Part Number: 49-1961

• Up to 6" front lift
• Up to 3.5" rear lift
• Addresses driveline system issue
• Re-positions transmission & pinion position for smooth driving
• Relocation brackets & bump stop extensions prevent over-compression

Includes:

• 3.5" lift rear springs
• 6" lift front springs
• Radius arm drop brackets
• Pitman arm
• Bump stops and extensions
• Front sway bar spacers
• Rear sway bar end links
• Front track bar relocation bracket
• Transmission cross member
• CNC machined Billet aluminum transfer case clocking ring
• Bilstein 5100 series shocks

Tire Fitment:

• Max 37" by 13.50" tire
• 9.5" - 10" wide -18 offset

• Estimated Installation Time: 7.5 Hours +/- 1 Hour (not including alignment and wheel & tire assembly)
• Please take into account tire and wheel choice, this will generally have a meaningful impact on the ride & handling experience.
• For use with ONLY new body style 2500 HD 4WD trucks with rear coil springs
• Not compatible with Auto-Ride or factory Air Suspension

• Any ReadyLIFT products containing missing or defective components will be covered under warranty by ReadyLIFT. ReadyLIFT leveling kit, block kits, and lift kit products are NOT intended for off-road abuse. Any abuse or damage as a result of off-road use voids the warranty. See the ReadyLIFT website for exceptions.
•  Warranty does not apply to discontinued, clearance, or outlet products.

• Wearable components including, but not limited to, shocks, ball joints, Heim joints, bushings, and steering extensions, are covered for up to 1-year.
• Free 5 Year/ 60,000 Mile Powertrain Warranty with qualifying suspensions.
