2019-2024 Ram 1500 6" Lift Kit w/ Big Bore Knuckle (49-1961)

Fits

Note: Will NOT work with factory 18" wheels or air ride suspension

Specially engineered for the Rams with factory air ride and those massive 22" wheels. ReadyLift has dedicated copious amounts of time and testing to ensure you get a kit that looks great, lasts long, and exceeds performance expectations on any terrain. Featuring dual-rate rear coil springs and rear control arm brackets that minimize small bump sensitivity and increase mid-stroke support. HD steel front cross-members and differential drop brackets retain factory geometry, ride quality, and handling while providing proper differential rotation to ensure there is no driveline vibration when in 4WD or Auto-4HI.

Part Number: 49-1961

• Up to 6" front lift & 3.5" rear lift
• Addresses driveline system issue
• Re-position transmission & pinion for smooth driving
• Relocation brackets & bump stop extensions prevent over-compression
• Maintains factory ride quality and handling
• HD steel front cross-members and differential drops retain factory geometry

Includes:

• 3.5" lift rear springs
• 6" lift front springs
• Radius arm drop brackets
• Pitman arm
• Bump stops and extensions
• Front sway bar spacers
• Rear sway bar end links
• Front track bar relocation bracket
• Transmission cross member
• CNC-machined Billet aluminum transfer case clocking ring
• Bilstein 5100 series shocks

Tire Fitment:

• 20x9" 0 offset - 37x12.50" tire
• Max with trimming: 20x10" -18 offset - 37x12.50"
• For use on Ram 1500 with factory 22" wheels. It will NOT fit 18" wheels

• Consider tire and wheel choice, this will generally have a meaningful impact on the ride & handling experience.
• Does not work with the 3.0-liter twin-turbo inline-six Hurricane engine ( available in some late 2024 models)
• For use with ONLY new body style 2500 HD 4WD trucks with rear coil springs

• NOT compatible with adjustable "air ride" suspension-equipped models, diesel engine applications, or Ram TRX




• ReadyLIFT Suspension Inc. and/or Dirty Diesel Customs are NOT responsible for any damage or failure resulting from improper installation.
• Click here to view installation instructions
