2015-2017 F-150 / Raptor Wheel Bearing Assembly (AX515195)

This Axiom Supply front wheel bearing and hub assembly is a complete bolt-in replacement for 13th-generation aluminum-body F-150s, covering 2015-2017 trucks with a 6-lug hub and integrated ABS sensor, including the 2017 Raptor. The rolled inner spindle design covers both 2WD and 4WD configurations, and the proprietary bearing and hub structure reduces hub-face deflection under towing loads, oversized tires, and lifted setups. It fits either the left or right front position and installs in about 2 hours with no modifications. Interchanges with Ford FL3Z-1104-A/C/E/F/H, MOOG 515195, Timken HA590485, and Motorcraft HUB403, among others.

Part Number: AX515195

• Precision tapered roller bearings packed with high performance grease for maintenance-free operation
• Grade 10.9 cold-formed, zinc-plated wheel studs for tensile strength and corrosion protection
• Durable ABS sensor built to maintain accurate signal transmission through heat, mud, and moisture
• Configuration: 6x135 bolt pattern with M14-1.50 lug studs
• Rolled inner spindle design accommodates both 2WD and 4WD systems
• Interchanges with Ford FL3Z-1104-A/C/E/F/H, MOOG 515195, Timken HA590485, Motorcraft HUB403, and more
• Complete bolt-in unit, fits both left and right spindle positions
• Proprietary bearing and hub structure reduces hub-face deflection under load for tighter steering response and improved braking stability

• 1 x Wheel Bearing & Hub Assembly with Integrated ABS Wire

• For trucks equipped with a 6-lug wheel hub and integrated ABS sensor
• Torque specs: axle nut 250 lb-ft, spindle bolts 133 lb-ft, main caliper bolts 184 lb-ft, lug nuts 150 lb-ft
• Typical installation time is approximately 2 hours with no special modifications required
