Description
Fits
Year |
Make |
Model |
Trim |
2001-2005 |
Chevrolet |
Silverado 2500 HD |
|
2001-2012 |
Chevrolet |
Silverado 2500 HD |
LT |
2001-2012 |
GMC |
Sierra 2500 HD |
SLT, SLE |
2001-2002 |
GMC |
Sierra 2500 HD |
SL |
2001-2006 |
Chevrolet |
Silverado 2500 HD |
LS |
2002-2005 |
GMC |
Sierra 2500 HD |
|
2003-2012 |
GMC |
Sierra 2500 HD |
WT |
2004-2012 |
Chevrolet |
Silverado 2500 HD |
WT |
2006-2006 |
GMC |
Sierra 2500 HD |
SL |
2007-2012 |
Chevrolet |
Silverado 3500 HD |
LT, LTZ, WT |
2007-2012 |
Chevrolet |
Silverado 2500 HD |
LTZ |
2007-2012 |
GMC |
Sierra 3500 HD |
SLE, SLT, WT |
2011-2012 |
GMC |
Sierra 3500 HD |
Denali |
2011-2012 |
GMC |
Sierra 2500 HD |
Denali |
For every 1° increase in intake air temperature will result in a 3hp loss. This kit also features HSP's high-flow turbo mouthpiece. This turbo mouthpiece will give you the ability to reroute your factory PCV system and remove the factory resonator box, eliminating unwanted engine oil gumming up the turbo and intake system. Featuring 3" mandrel bent hot side and cold side tubes with a max flow Y-bridge and turbo mouthpiece.
The factory hot side intercooler tube on the Duramax is notorious for failure. The two-piece design from the factory has crimped-on boots that have a tendency to fail under heat and pressure, it's only a matter of time before it leaves you stranded on the side of the road. The factory cold side also has its limitations and is made of plastic with an unreliable clamping system.
Part Number: 583-1-HSP
Features
- Mandrel bent 4 1/2" intake tube
- Featuring 3" mandrel bent hot side and cold side tubes with a max flow Y-bridge
- Heat shield box
- High-flow turbo mouthpiece
- Max Flow Y-bridge
- 5-layer silicone boots
- 2" passenger side up pipe w/ .120" tubing
- Keeps EGT's low & increases performance
Includes:
- 3x 3" x4" Straight boot
- 7x 3" t-bolt clamps
- 1x 2.25" - 3" Reducer boot
- 1x 2.25"h t-bolt clamp
- 1x Duramax pre-made hose
- 1x M6x1.016mm flange bolt
- 4x M6x1.0x20mm flange bolt
- 2x M6x1.0x25mm flange bolt
- 1x 1/2" worm gear clamp
- 1x 5/8" worm gear clamp
- 2x 1/8" NPT brass plug
- 1x rear cover coolant plug
- 1x coolant plug o-ring
- 1x 3/4" to 5/8" heater hose connector
- 1x 3/8" coolant plug
- 2x M4x7x10mm bolt
- 3x 10-32 x 3/8" Button head screws
- 4x 1/8" aluminum rivet
- 1x 4" - 4.5"reducer boot
- 1x 4" T-bolt clamp
- 1x 4.5" T-bolt clamp
- 1x 4.5" Filter
- 1x up-pipe gasket (turbo side)
- 1x up-pipe gasket (manifold side)
Notes
Compatible with:
