2005+ Powerstroke HD Tie Rod (8602-11)

Fits

Improve strength, and durability & eliminate any chance of bending, tie rod flop & steering dead-spot commonly encountered with hydro assist setups with Synergy's HD Tie Rod. 100% bolt-on & fully adjustable these tie rods are a good upgrade for any Powerstroke owner.

Part Number: 8602-11

Superseded Part Number: 8602-01

• Over 40% stronger than the stock tie rod
• Tie Rod bolts right into the factory mounts with no additional wheel requirements
• No factory tie rod components need to be reused
• Includes Synergy HD Metal on Metal Tie Rod Ends with oversized 1 1/4" shank
• Tie Rod is CNC formed from 1.75" x .188 wall seamless chromoly tubing and heat treated after forming
• Abrasion-resistant powder coat finish for maximum durability and corrosion resistance
• Synergy Double Adjuster Sleeve allows adjustment of tie rod length without removing it from the vehicle
• Both ends of the bar use pinch bolts instead of jam nuts to simplify installation and adjustment
• Max extended length: 62.5"
• Min collapsed length: 59.75"

Includes:

• (1) 8602 Ford Super Duty tie rod
• (1) 4150-L Ford Super Duty single plane tie rod end
• (1) 4151-L Ford Super Duty through shaft tie rod end
• (1) 3622-12-12-PL Adjuster sleeve 1 4151-L Ford1/4-12 LH Shank Tie Rod End, Thru Shaft

• Click Here

• Replacement Tie Rod Ends:
  (1) 4151-L
  (1) 4150-L

• Backwards compatible with factory drag link

• Synergy drag link (8600-01) recommended but not required

• For use in the under-knuckle configuration for Super Duty trucks

• Synergy High-Performance Grease recommended (4119) to be used with all Tie Rod Ends

• Synergy Premium Copper Infused Anti-Seize (4118) to be used with all threaded components (TRE's and Adjuster Sleeve)
