2005-2016 Powerstroke 4-6" 4-Link Upgrade Kit (BDS980H)

BDS Part Number: BDS980H
$1,655.76 CAD

Purchase to earn 1655 Dirty Dollars Learn More

This product ships for free to most Canadian locations! Learn more

Description

Fits

Year Make Model Type Lift Location
2005-2021 Ford F250/F350 Super Duty 4WD 4"-6" Front



Upgrade to a better suspension system design with a BDS true 4-Link long arm system for your 2005-12 Ford Super Duty.  If you want the best suspension system that can handle the most demanding environments, a smooth ride, better travel, and reduce stress on the vehicle and its suspension components, this 4-Link upgrade is an ideal choice.

Part Number: BDS980H

Features

  • Works with 4-6" lifts
  • Includes complete bolt-on control arm mounting system
  • Oversize high-performance greaseable urethane bushings
  • High-quality urethane provides more stability in steering
  • Massive 2" diameter x .25" wall upper and lower control arms
  • Includes complete bolt-on control arm mounting system
  • Maintains consistent caster angle through full wheel travel for optimal handling characteristics
  • Better axle control
  • The new arms use the factory mounting hardware at the frame and a combo of factory and provided hardware with cam locks at the axle.
  • Independent upper and lower links
  • Consistent caster angle through full wheel travel for optimal handling
  • Powdercoated Black

Includes:

  • Two Lower 4-Link Arms
  • Two Upper 4-Link Arm
  • One 4-Link Frame Bracket - (Driver & Passenger Side)
  • Eight Link Bushings
  • Four (1.0 x 0.120 x 3.250) Sleeves
  • 90 Degree Grease Zerk
  • One Bolt Pack

Notes

  • As a result of the location of the long radius arm suspension, support locations are limited. Use your best judgment while supporting the vehicle with sufficient strength stands at appropriate locations. The radius arms will need to move freely during this installation.
  • The new Super Duty radius arms can be sold as an upgrade for the Ford F250/F350 with 2-4" of front lift. They cannot be used with radius arm drop brackets at these heights.  Therefore, if someone has a current BDS radius arm drop bracket kit, they will need to remove the drop bracket to install these arms.
  • For those with 6" of front lift, the radius arms can be installed with the drop brackets as a direct swap for the factory radius arms - only caution would be that the caster may need to be checked if ball joint cams are installed.

Installation

Warranty

  • Supplemental Drivetrain Limited Protection provided by 560Plus.com - 5 Year/60,000 Miles on Ford, Nissan, & Toyota vehicles and 5 Year/100,000 Miles on Dodge/Ram, GMC, & Jeep vehicles.
  • Free, no cost protection for BDS customers
  • Could save thousands of dollars on possible repairs
  • An easy online registration process
  • Available for most late-model vehicles
