1994.5-2003 Powerstroke Stage 1 High Pressure Oil Pump

KC Turbos
Regular price $1,316.47 CAD

Years

The Details

* Asterisks indicate a required selection.

Acknowledgment *

This product will automatically bundle the following item:

Purchase to earn 1316  Dirty Dollars Learn More

This product ships for free to most Canadian locations! Learn more

Description

The CNC-Fab Stage 1 High Pressure Oil Pump is built and bench-tested to outflow the OEM 7.3L Powerstroke HPOP and support hybrid injectors up to 230cc/100%. Each pump is verified to a minimum 5 GPM, with most units flowing 5.1-5.6 GPM, making this the right reliability and headroom upgrade for daily-drivers, work trucks, and mild-tow builds.

Part Number: 424015 / 424017

Features

  • Bench-tested to a 5 GPM minimum, typically 5.1-5.6 GPM
  • Supports hybrid injectors up to 230cc/100%
  • OBS and early 1999 builds use Super Duty internals with a 17 degree swash plate for added volume
  • Steel thread inserts prevent thread damage
  • New Viton o-rings and pump gasket included
  • 424015 (1994.5-1995) includes built-in anti-drain back for the OBS front engine cover

Additional Information

Injector Compatibility:

Compatible:

  • 160cc–205cc injectors
  • 160/30, 180/30, 160/80, 205/30, 205/80
  • 205/80 and most towing performance builds

Not compatible:

  • 238cc and Larger A-code injectors
  • B-code (Super Duty) performance injectors
  • Extreme competition setups

Core Return:

CORES FOR 94.5-95 HPOP MUST BE THE CORRECT HOUSING TO RECIEVE FULL CREDIT. 96-03 CORES WITHOUT THE CHECK VALVE WILL BE ACCEPTED WITH A 25% REDUCTION OF CORE REFUND.

See Cnc-Fabs Core Policy HERE

Installation

Questions and Answers

Don't see your question? Ask us anything about this product.

  • Does it have warranty?

    1-year manufacturer warranty covering parts.

  • Gaskets/Seals included?

    Yes, new Viton O-rings and pump gasket included.
